LMV358_LMV321_LMV324

LMV321TP/358TP/324TP are CMOS single, dual,and quad op-amps with low offset, stable high frequency response, low power, low supply voltage,and rail-to-rail inputs and outputs.

应用领域

• Active Filters, ASIC Input or Output Amplifier
• Sensor Interface
• Smoke/Gas/Environment Sensors
• Portable Instruments and Mobile Device
• Audio Output
• PCMCIA Cards
• Battery or Solar Powered Systems
• Medical Equipment
• Piezo Electrical Transducer Amplifier

特性特点

LMV321TP/358TP/324TP are CMOS single, dual,and quad op-amps with low offset, stable high frequency response, low power, low supply voltage,and rail-to-rail inputs and outputs. They incorporate 3PEAK’s proprietary and patented design techniques to achieve best in-class performance among all micro-power CMOS amplifiers.

The LMV321TP/358TP/324TP are unity gain stable with Any Capacitive Load with a Constant 1.27MHz gain-bandwidth product, 0.9V/μs slew rate while consuming only 40μA of supply current per amplifier.Analog trim and calibration routine reduces input offset voltage to below 3.5mV. Adaptive biasing and dynamic compensation enables the LMV321TP/358TP/324TP to achieve ‘THD+NOISE’ for 1kHz and 10kHz 2VPP signal at -105dB and -90dB,respectively. Beyond the rails input and rail-to-rail output characteristics allow the full power-supply

voltage to be used for signal range.

This combination of features makes the LMV321TP/358TP/324TP superior among rail-to-rail input/output CMOS op amps in its power class. The LMV321TP/358TP/324TP are ideal hoices for battery-powered applications because they minimize errors due to power supply voltage

variations over the lifetime of the battery and maintain high CMRR even for a rail-to-rail input

op-amp.The LMV321TP/358TP/324TP can be used as cost-effective plug-in replacements for many commercially available op amps to reduce power and improve input/output range and performance.

主要特征

  • Uspangrade to LMV321/LMV358/LMV324 Family
    Stable 1.27MHz GBWspan with Low IQ of Only 40μA
    Tyspanical spaner Amspanlifier
    0.9V/μs Slew Rate
    Unity Gain Stable for ANY CAspanACITIVE Load
    Offset Voltage: 3.5mV Maximum
    Offset Voltage Temspanerature Drift: 0.6uV/°C
    Inspanut Bias Current: 1spanA Tyspanical
    THD+Noise: -105dB at 1kHz, -90dB at 10kHz
  • CMRR/spanSRR: 110dB/102dB
    Beyond the Rails Inspanut Common-Mode Range
    Outspanuts Swing to within 5mV Tyspanical of each Rail
    No spanhase Reversal for Overdriven Inspanuts
    No Crossover Distortion
    Drives 2kΩ Resistive Loads
    Single +2.1V to +6.0V Suspanspanly Voltage Range
    –40°C to 125°C Ospaneration Range
    ESD Rating: &nbsspan;Robust 8KV – HBM, 2KV – CDM and 500V – MM
    Green, spanospanular Tyspane spanackage
